2014
UPTOWN CRMO 29

https://tech.commencal.com/tech/index.php?fiche=80&lang=UK
SPECS

FRAME New 2014 UPTOWN CrMo 29, VB version, internal brake housing path
FORK UPTOWN 29” CrMo fork VB
HEADSET NECO 1”1/8 integrated, campy style, sealed bearings
STEM COMMENCAL uptown CrMo 50mm ø25,4mm, 0° angle
BAR COMMENCAL CrMo, 2” rise, ø25,4mm, 640mm
GRIPS COMMENCAL by Velo
BRAKES PROMAX V-Brake linear spring
BOTTOM BRACKET NECO square 68mm
CRANKS LASCO alloy 170mm 36t
CHAIN YABAN half link black
COG DICTA 17t
RIMS JALCO 29” single wall VB 36h
HUBS JOYTEC 36h, loose ball bolt version
SPOKES Steel 1,8mm ed black - steel 12mm black
TIRES VITTORIA tatoo 29”x2.30”
SEATPOST COMMENCAL alloy no offset ø27,2mm, 350mm
SADDLE COMMENCAL by Velo


SIZES S / M / L / XL
COLOUR Neon Yellow Matt Finish
BIKE WEIGHT(kg/lbs) 13,70
FRAME WEIGHT(kg/lbs) N/A
NOTE WELLGO nylon, low profile pedals, alloy anodised fender kit, LEZYNE femto light kits

VIP frame available & Frame available


SPOKE LENGTH
WHEEL NON DRIVE SIDE / LEFT DRIVE SIDE / RIGHT
FRONT 284 mm 286 mm
REAR 288 mm 288 mm
PARTS
Headset
EC34 / 28,6 - EC34 / 30
Buy
Bottom Bracket
BSA 68mm
Buy
Rear hanger
/
Buy
FreeHub Body
802N
-
