2014

UPTOWN AL LIGHT GREEN 2014
SPECS

FRAME New 2014 UPTOWN Al 29, alloy 6061 formed
FORK UPTOWN 29” CrMo fork disc
HEADSET NECO 1”1/8, semi integrated, ball retainer
STEM COMMENCAL 60mm, ø31,8mm, 10° angle
BAR COMMENCAL ø31,8mm, alloy 6061, 1”rise, 640mm
GRIPS COMMENCAL by Velo
BRAKES TEKTRO HDC330 hydraulic disc brake 160mm/160mm, with reach adjustment
SHIFTERS SRAM x4 8 speed
REAR MECH SRAM x4 8 speed
BOTTOM BRACKET NECO square 68mm
CRANKS LASCO alloy 170mm 36t, double plastic bash
CHAIN YABAN 8 speed
CASSETTE SRAM pg820 11-32t
RIMS JALCO 29” single wall disc 36h
HUBS JOYTEC 36h, loose ball, bolt version
SPOKES Steel 1,8mm ed black - steel 12mm black
TIRES VITTORIA tatoo 29”x2.30”
SEATPOST COMMENCAL alloy no offset ø31,6mm, 350mm
SADDLE COMMENCAL by Velo


SIZES S / M / L / XL
COLOUR Light Green Matt Finish
BIKE WEIGHT(kg/lbs) 13,50
FRAME WEIGHT(kg/lbs) N/A
NOTE WELLGO nylon, low profile pedals, alloy anodised fender kit, LEZYNE femto light kits

VIP frame available & Frame available



LONGUEUR DES RAYONS
ROUE GAUCHE / CÔTÉ SANS TRANSMISSION DROIT / CÔTÉ TRANSMISSION
AVANT 284 mm 286 mm
ARRIÈRE 286 mm 284 mm
PARTS
Jeu de Direction
ZS44 haut et bas
Acheter
Boitier de pédalier
BSA 68mm
Acheter
Patte de dérailleur
ElCamino
Acheter
Corps de roue libre
D144DSE
8/9/10S - W/O cog
Acheter
