| FRAME | 2018 NEW META HT CRMO FRAME 650B, triple butted | | SHOCK | | | FORK | ROCK SHOX LYRIK RC, 160 mm, compression, rebound, boost | | HEADSET | RIDE ALPHA ZS44 / EC44 | | STEM | NEW RIDE ALPHA, aluminium 6061, 40 mm, 31.8 mm, 0° angle | | BAR | RIDE ALPHA, Alloy 7075, double butted, 30 mm rise, 780 mm, 31.8 mm | | GRIPS | RIDE ALPHA, ergonomic grips, plastic one lock, super soft compound | | BRAKES | SRAM LEVEL, 200 mm / 180 mm | | SHIFTERS | SRAM NX, 1 x 11 speed | | FRONT / REAR MECH | / SRAM NX, 11 speed | | BOTTOM BRACKET | SRAM GXP Press Fit BB92 | | CRANKSET | SRAM NX X-Sync steel, 32T, 170 mm on S/M, 175 mm on L/XL | | CHAIN | SRAM PC 1110 | | CASSETTE | SRAM PG 1130, 1142T | | RIMS | E13 TRS, 32 holes, tubeless ready, 30 mm inner width | | HUBS | FORMULA, 32 holes, sealed bearings | | SPOKES / NIPPLES | PILLAR Spokes, steel, 2 mm black / brass nipple 12 mm black Nylock | | TYRES | MAXXIS MINION DHF 27.5" x 2.5" WT EXO/TR/3C front and MAXXIS DHRII 27.5" x 2.3" EXO/TR/2C rear | | SEATPOST | KS E-30i-S, 31.6 mm, 100 mm on S, 125 mm travel on M, L, XL, southpaw alloy lever | | SADDLE | RIDE ALPHA 278 mm, Ti-Alloy rails | | WEIGHT | 14 kg | | PEDALS INCLUDED | No | | ACCESSORIES | Chainstay protector, seatstay protector | |
